Product Detail
Model: BTWL-A1SO-120
5.7-inch 120W Square Swivel-Bracket LED Work Light
As the highest-output model in the A1SO square swivel-bracket series, this 5.7-inch work light delivers 10,200 actual lumens from 120W. The 360-degree bracket helps direct flood or spot illumination across larger work areas, while the 9–32V DC input supports a range of equipment platforms.
Key Features
120W Power
10,200 lm Output
Flood / Spot Beam Options
360° Swivel Bracket
IP68 Water Protection
Size
5.7-inch
Power
120W
Operating Voltage
9-32V DC
Actual Lumens
10,200
Beam Pattern
Flood Beam / Spot Beam
Color Temperature
6000K
IP Rating
IP68
Housing Material
Die-cast aluminum
Lens Material
PC
Mounting / Bracket
304 Stainless Steel Bracket
Cable / Connector
Bare Wire Leads / Deutsch DT Connector
Operating Temperature
-40°C to +85°C
Certifications & Compliance
CISPR 25 Class 4
